Model

Dimension

13000mm ×2490mm×2860mm(outside dimension ),12800×2300×1800mm (inside dimension)

Curb Weight

About 6.8-8.6T

Loading Capacity

≤60 Tons

Axle

13 T/16T, FUWA /BPW /Huajing Brand three axles

Rim

9.00-22.5

Tire

12.00R22.5/ 315 80R22.5

King pin

JOST brand 2.0 or 3.5inch (bolted or welded type)

Support leg

JOST brand D200T or Chinese brand 28Tons (Double speed)

Main beam

Height: 500mm Upper plate: 14mm Middle Plate: 8mm,Bottom Plate is 16mm; Material: Q345B Steel

Side beam

16mm or 18mm steel channel (Material: Q235steel ).

Side tube

7 square tube on each side of trailer Tube size : 10×10mm

Brake chamber

WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber (TKL brand); 45L air tanks

ABS

Optional

Twist Locks

Four ,Eight or Twelve pieces (lifting type or twist Screw type)

Valve

WABCO valve

Light

LED light (specially intended for oversea market )

Voltage

24V

Receptacle

7-pin Socket (for 7 wire harness)

Tool box

1m × 0.5m × 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs.)

Painting

Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats.

Shipping Terms

By bulk cargo carrier, RORO or 40HQ container.
